HWATEK 철사와 케이블 CO., 주식 회사.
| 정격 전압: | 450/750v | 정격 온도: | 75oC |
|---|---|---|---|
| 도체 자료: | 나동선은 좌초했습니다 | 지휘자 크기: | 136/0.15mm+10/1#구리 포일+1000D Vectran | 40/0.150+10/0.19mm 구리 포일+200D Vectran |
| 단열재: | TPE | 절연 두께: | 0.80mm | 0.50mm |
| 최소 절연 두께: | 0.62mm | 0.35mm | 외경: | 3.70 ± 0.15mm | 2.50 ± 0.15mm |
| 재킷 재료: | TPE | 재킷 두께: | 1.90mm |
| 최소 재킷 두께: | 1.51mm | 케이블 외경: | 13.80 ± 0.30mm |
| 최대 DC 저항: | 7.98Ω/km | 26Ω/km | 인장 강도: | ≥10mpa |
| 연장: | ≥250% | ||
| 강조하다: | Flame Test GB/T 18380.12 EV Charging Cable,Outdoor AC EV Power Charger Cable,Bare Copper Stranded Electric Vehicle Charging Cable |
||
| SPECIFICATION | CABLE NAME | EV CABLE |
|---|---|---|
| CABLE SPEC | 3Cx2.5mm2+1Cx0.75mm2+W | |
| RoHS Compliant | Yes | |
| ITEM | A: 3C×2.5mm2 | B: 1C×0.75mm2 |
|---|---|---|
| CONDUCTOR | Bare copper stranded | |
| Size | 136/0.15mm+10/1#copper foil+1000D Vectran | 40/0.150+10/0.19mm copper foil+200D Vectran |
| O.D.(Ref) | 2.10mm | 1.30mm |
| INSULATION | Material: TPE | |
| Nom. thickness | 0.80mm | 0.50mm |
| Min.thickness at any point | 0.62mm | 0.35mm |
| O.D. | 3.70±0.15mm | 2.50±0.15mm |
| CABLING | Filler: PP rope Material: Nonwoven tape Assembly: 3Cx2.5mm2+1Cx0.75mm2+W |
|
| JACKET | Material: TPE Nom. thickness: 1.90mm Min.thickness at any point: 1.51mm O.D.: 13.80±0.30mm |
|
| ELECTRICAL CHARACTERISTICS | PHYSICAL PROPERTIES |
|---|---|
| Rated voltage: 450/750V | Tensile strength: ≥10MPa |
| Rated temperature: 75ºC | Elongation: ≥250% |
| Max. DC conductor resistance(20ºC): A: 7.98Ω/km B: 26Ω/km |
High temperature and pressure:(80±2ºC×4h) ≤50% |
| Voltage withstand test: A: AC 3.5kV/15min B: AC 1.5kV/15min |
Flame test: GB/T 18380.12 UV Resistance: 720h CQC1103-2015 |
