제품 상세 정보:
결제 및 배송 조건:
|
| 지휘자: | 드러난 구리 | 격리: | EVI-2 |
|---|---|---|---|
| 재킷: | EVM-1 | 케이블 모양: | 둥근 |
| 신청: | 산업, 가전제품, 의료, EV 충전, 그린 에너지 등 | 포장: | 릴에서 싸여집니다 |
| 휘장: | 1500V DC | 온도: | -40~90C |
| Pn: | HT2504389 |
| Construction | |||||
| Conductor | |||||
| Cross section | A:2C×50.0mm2 | B:1C×25.0mm2 | C:3×2C×0.75mm2 | ||
| Construction | 1596/0.20mm | 798/0.20mm | 40/0.15mm +Tinsel+Kevlar |
||
| Strand Dia.(Ref.) | 9.90mm | 7.10mm | 1.30mm | ||
| Insulation | EVI-2 | ||||
| Nom.Thickness | 1.10mm | 1.00mm | 0.50mm | ||
| Min.Thickness | 0.90mm | 0.85mm | 0.35mm | ||
| Insulation Dia. | 12.40±0.40mm | 9.20±0.30mm | 2.35±0.15mm | ||
| Insulation colour | 1.red 2.black | B.yellow/green | C1.violet&white C2.orange&blue C3.gray&brown | ||
| Twisted pair | / | / | 4.7mm | ||
| Filler | PP rope | ||||
| Material | Non-woven | ||||
| Assembly | 2C×50.0mm2+1C×25.0mm2+6C×0.75mm2+W | ||||
| Jacket | EVM-1 | ||||
| Nom.Thickness | 2.20mm | ||||
| Min.Thickness | 1.77mm | ||||
| Outer Dia. | 32.00±1.00mm | ||||
| Colour | Black | ||||
Conductor Bared copper stranded
Cross section 2C×50.0mm2+1C×25.0mm2+6C×0.75mm2+W
Construction 1596/0.20mm ,798/0.20mm,40/0.15mm
Elongation ≥100%
Aged condition 110℃×168H
Insulation EVI-2
Nom.Thickness 1.00 mm
Min.Thickness 0.85 mm
Insulation Dia.12.40±0.40mm
nsulation: :red, black
Jacket EVM-1
Reference standard:IEC standard
Nom.Thickness 2.2 mm
Outer Dia. 32.00±1.00mm
Colour per request
UL758-E258652-20060111A-CertificateofCompliance(2)...
| Electric Performance | ||||||
| Rated Temperature | -40~90℃ | |||||
| Voltage rating | 1500V DC | |||||
| Max.conductor DC resistance(20℃) | A:0.423Ω/km B:0.848Ω/km C:27.4Ω/km | |||||
| Dielectric Strength | AC 3.5kV/5min | |||||
